7000Nits LED Passenger Information Screen Digital Traffic Message Sign

Product Description

7000Nits LED Passenger Information Screen Digital Traffic Message Sign

Digital traffic message sign 6000 ~ 7000 nits Railway Station Information Display Screen

Intelligence

1. A dual brightness automatic adjustment system is built into the screen, which effectively improves the dimming accuracy of the system and can meet automatic/manual adjustment; ensure sufficient brightness during the day and no glare at night;
2. The train time information and digital information are sent to the train display screen through the train communication control unit (TCCU), and each LED display screen displays the relevant information through the Ethernet-based user data packet protocol (UDP) controlled by the branch switch, embedded The software is updated online and is being monitored.
3. A single-point fault feedback system is built into the screen to ensure that the working status of the induction screen can be grasped in the control room at the first time;
4. GPS and central computer control system ensure that the PIDs of the station can be correlated with each other.

energy saving:
1. Ultra-wide viewing angle, suitable for multi-angle viewing, more convenient and more intimate;
2. Display the arrival and departure timetable, real-time information and business information, adopt high-brightness LED technology and automatic/manual dimming technology to ensure the best visibility, and at the same time have the characteristics of energy saving and environmental protection;
3. All products are selected, designed and produced according to RoHS standards;
4. The production strictly follows the ISO14001 standard.

Safety & Reliability

1. All metal equipment casings, piping systems, and junction boxes are painted.
2. High protection level: IP65 (outdoor station square, platform), IP54 or 30 (station hall, train bus compartment), selected according to environmental conditions to ensure 360° waterproof and dustproof structure;
3. Dual-voltage working mode, 25% energy saving, redundant power supply design, effectively enhance reliability and long service life;
4. Active heat dissipation structure of double-layer doors on the screen body, the structure is airtight;
5. High-quality energy-saving LED modules, guaranteed 10-year service life, module mean time between failures (MTBF) ≥ 80,000 hours.
