Custom Made P10 VMS Parking Display 160×160mm Module Energy Saving
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966 |
| Model Number: | YH-P10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 12 Piece/Pieces |
|---|---|
| Price: | $55-65 Piece/Pieces |
| Packaging Details: | Wooden Box |
| Delivery Time: | 42 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 11000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Usage: | Parking | Shape: | Square |
|---|---|---|---|
| Logo: | Customized Logo | Warranty: | 2 Years |
| Module Dimension: | 160×160mm | Module Resolution: | 16×16 |
| Screen Weight: | 65kg/m² | Brightness Adjustment: | 32/256 |
| High Light: | P10 VMS Parking,160×160mm Module VMS Parking,P10 Car Parking Display |
||
Product Description
Custom Made P10 VMS Parking Display 160×160mm Module Energy Saving
p10 custom made led parking lot counter display parking display 10000 pixels/m² 960*960 mm
The outstanding features of our led products areenvironmental-friendly, energy-saving and long life-span. All of our LEDproducts have approved by CCC, CE, ROHS, FCC, ISO9001 quality certificates authorities. Furthermore, our LED products were exported to more than 90 countries till now such as Sweden, USA, Brazil, France, Japan, Thailand, Italy,Australia, Spain and etc. Those LED products were widely used in both indoorand outdoor places like hall, hotel, exhibition room, public square, symbols,building and TV stage background and etc.
1. Energy saving and environmental protection
The light-emitting element of the LED display is LED. Because the power of a single LED is very low, generally 0.04 ~ 0.08W, the power is several times lower, but the effect is much better. The LED display is made of environmentally friendly materials and is recyclable. It will not cause pollution and damage to the environment due to heavy use.
2. Posting information is simple and convenient
Connect to a computer through a data cable connection or wireless communication, and set up in the computer to publish advertising content, conveniently and quickly.
Our Advantages:
1). Over 20years experience in led display sign industry enhances our good reputation throughout many countries. Our agent work with us and they are spead in world wide, cover Europe,America,Asia,Arifca,Australia and etc.
2). OEM and ODM services are provided due to customers' requirement.
3). CE RoHs certificates and quality control by ISO9001-2008, providing our products with quality assurance.
4). Excellent raw material suppliers provide a good foundation for the best quality of the products.
5). Strict raw material inspection improves the product qualification rate, extends the life.
6).100% aging line test before packing minimizes the possibility of defective products flowing out of the factory.
7). Quality inspection in random before shipping assures products reliability with technical data.
8).We offers a great variety of goods with all kinds of quality that can meet the requirement of most markets in the world.
| Item | YHT-VMS-D10 | YHT-VMS-D12 | YHT-VMS-D16 | YHT-VMS-D20 | YHT-VMS-D25 | YHT-VMS-D31.25 |
| Pixel pitch | 10mm | 12mm | 16mm | 20mm | 25mm | 31.25mm |
| LED type | 346 DIP | 346 DIP | 510 DIP | 510 DIP | 510 DIP | 510 DIP |
| Pixel density | 10000 pixels/m² | 3944 pixels/m² | 3906 pixels/m² | 2500 pixels/m² | 1600 pixels/m² | 1024 pixels/m² |
| Cabinet material | 2mm aluminum Alloy | |||||
| Screen weight | 65kg/m² | 65kg/m² | 65kg/m² | 65kg/m² | 65kg/m² | 65kg/m² |
| Cabinet dimension | 960×960 mm | 960×960 mm | 1024×1024 mm | 960×960 mm | 1000×1000 mm | 1000×1000 mm |
| Brightness | L3: EN12966 (Red: >3100nits, Green>3720nits,Blue>1240nits, Amber>7440nits, | |||||
| Driving method | 4S | 2S | Static | Static | Static | Static |
| Brightness adjustment | 32/256 | 32/256 | 32/256 | 32/256 | 32/256 | 32/256 |
| Color coordinates | / | / | C2: EN12966 | C2: EN12966 | C2: EN12966 | C2: EN12966 |
| Viewing angle | H.110°, V.50° | H.110°, V.50° | H.30°, V.30°(B6:EN12966) | |||
| Contrast ratio | / | / | R3: EN12966 | R3: EN12966 | R3: EN12966 | R3: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz | >90+ Hz | >90+ Hz | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | |||||
| Signal transfer | Cat 5 Network Cable, RS232,RS485 optional | |||||
| Display capacity | Text, image, graphics animations | |||||
| Lifespan | >100000 hrs | >100000 hrs | >100000 hrs | >100000 hrs | >100000 hrs | >100000 hrs |
| Power supply | 12-24v /220v | 12-24v /220v | 12-24v /220v | 12-24v /220v | 12-24v /220v | 12-24v /220v |
| Max. Power consumption | 300W/m² | 300W/m² | 200W/m² | 200W/m² | 200W/m² | 200W/m² |
| Avg. Power consumption | 100W/m² | 100W/m² | 70W/m² | 70W/m² | 70W/m² | 70W/m² |
| Operation temperature | -25~ 60°C | |||||
| Storage temperature | -40~ 80°C | -40~ 80°C | -40~ 80°C | -40~ 80°C | -40~ 80°C | -40~ 80°C |
| Operating humidity | 10%~ 90% | 10%~ 90% | 10%~ 90% | 10%~ 90% | 10%~ 90% | 10%~ 90% |
| Store humidity | 15%~ 95% | 15%~ 95% | 15%~ 95% | 15%~ 95% | 15%~ 95% | 15%~ 95% |
