Outdoor VMS LED Matrix Message Display Lane Control Speed Limit Board
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-OT10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 16 Square Meter/Square Meters |
|---|---|
| Price: | $1300-2600 Square Meter/Square Meters |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3180 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixels: | 10mm | Pixel Density: | 10000 Pixels/m² |
|---|---|---|---|
| Module Dimension: | 320×160 Mm | Contrast Ratio: | R2: EN12966 |
| Display Control: | Asynchronous Control System Available | Max. Power Consumption: | 400W/m² |
| High Light: | VMS LED Matrix Message Display,P16 LED Matrix Message Display,VMS Speed Limit Board |
||
Product Description
Outdoor VMS LED Matrix Message Display Lane Control Speed Limit Board
Outdoor P10 P16 Module Variable Message Display Speed Limit Board Lane Control Matrix Message Display
Better contrast ratio
The surface of each optical len is designed with carved strips that could tremendously reduce light reflection.
High stability
Less manual production and component processes, less potential failure rate, bringing the new module up to a new level of stability.
High colour consistency
With a much improved flatness, diode spectrum and brightness are able to remain the same, making the colour more consistent and content more readble.
WAY YAHAM
Short Delivery Term
YAHAM manufactures all orders according to customer expectations. YAHAM realizes the importance of short delivery terms for customers because of that YAHAM aims to manufacture all his orders within promised dates.
High Quality Production
YAHAM use all its raw metarials from ISO certificated products. YAHAM quality staff check all raw metarials before&after all processes to meet quality requirements.
Competitive Price
YAHAM believes to give competitive prices, it should push its own suppliers for competitive prices.
| Pixel pitch | 10mm | 16mm | 20mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 10000 pixels/m² | 3906 pixels/m² | 2500 pixels/m² |
| Module dimension | 320×160 mm | 256×128 mm | 320×160 mm |
| Module resolution | 32×16 | 16×8 | 16×8 |
| Screen weight | 65kg/m² | ||
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | ||
| Brightness adjustment | 32/256 | ||
| Refresh rate | >90+ Hz | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | ||
| Display capacity | Text, image, graphics animations | ||
| Power supply | 12-24V DC/110-230V AC | ||
| Avg. Power consumption | 130W/m² | 80W/m² | 70W/m² |
| Operation temperature | -25~ +60°C | ||
| Storage temperature | -40~ +80°C | ||
| Store humidity | 15%~ 95% | 15%~ 95% | 15%~ 95% |
| Maintenance method | Rear service | Rear service | Rear service |
| EN12966 | compliance | compliance | compliance |
