Vehicle Mounting LED VMS Signs P25 Full Color Road Safety Dynamic Message Signs
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-OT25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 8 Square Meter/Square Meters |
|---|---|
| Price: | $1100-2300 Square Meter/Square Meters |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 11 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3880 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixels: | 25mm | Pixel Density: | 10000 Pixels/m² |
|---|---|---|---|
| Module Resolution: | 32×16 | Driving Method: | 2S |
| Power Supply: | 12-24V DC/110-230V AC | Brightness: | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) |
| High Light: | Dynamic Message Signs P25,Vehicle Mounting LED VMS Signs,Full Color LED VMS Signs |
||
Product Description
P25 Full Color Its Road Safety Traffic Control Vehicle Mounting LED Sign Board Dynamic Message Signs
Slimline Lift Face Signs
1. Offers flexibility for communicating critical advisories to motorists traveling at low to medium speeds.
2. Ideal for event management, incident management, and travel time applications.
3. Designed for roadside or mast-arm mounting.
Lane Management Systems
Communicate lane specific messages to motorists.
Easily and safely reverse lane direction as needed for optimum traffic flow.
Dynamic Message Signs (DMS) provide motorists with information about traffic tie-ups, congestion and advise motorists to seek alternate routes when there are major delays or road closures.
The DMS message display is controlled by a built-in cell phone modem. Commands to the signs are issued by the MOC in order to inform approaching motorists of current traffic alerts.
| Item | YHT-VMS-OT10 |
| Pixel pitch | 10mm |
| LED type | 3 in1 SMD+lens |
| Pixel density | 10000 pixels/m² |
| Module dimension | 320×160 mm |
| Module resolution | 32×16 |
| Cabinet material | 2mm aluminum Alloy |
| Screen weight | 65kg/m² |
| Cabinet dimension | 960×960 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) |
| Brightness adjustment | 32/256 |
| Color coordinates | C2: EN12966 |
| Refresh rate | >90+ Hz |
| Display control | Asynchronous control system available |
| Display capacity | Text, image, graphics animations |
| Lifespan | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC |
| Max. Power consumption | 400W/m² |
| Avg. Power consumption | 130W/m² |
| Operation temperature | -25~ +60°C |
| Storage temperature | -40~ +80°C |
| Store humidity | 15%~ 95% |
| Maintenance method | Rear service |
| EN12966 | compliance |
