Multi Color Dynamic Message Signs P20 VMS Outdoor Variable Message Signs For Highway
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-OT12 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 19 Square Meter/Square Meters |
|---|---|
| Price: | $1210-2260 Square Meter/Square Meters |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 18 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 4350 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixels: | 12mm | Contrast Ratio: | R3: EN12966 |
|---|---|---|---|
| Refresh Rate: | >90+ Hz | Signal Transfer: | Cat 5 Network Cable, RS232,RS485 Optional |
| Store Humidity: | 15%~ 95% | Brightness Adjustment: | 32/256 |
| High Light: | P20 Dynamic Message Signs,Dynamic Message Signs IP65,Outdoor Variable Message Signs |
||
Product Description
Multi Color Dynamic Message Signs P20 Vms Outdoor Variable Message Signs for Highwayign Board IP65
Features
1,Full color DMS allow you to customize your message with MUTCD compliant graphics
2,NTCIP, NEMA TS4, AASHTO, and MUTCD compliant signs manufactured in an ISO 9001:2015 certified facility
3,Sign housings designed to AASHTO Standard Specifications for Structural Supports for Highway Signs, Luminaries, and Traffic
Signals
4,Sign housing manufactured with corrosion resistant aluminum alloys to withstand harsh roadside conditions and weather
environments
5,Highest quality LEDs for uniform color and brightness
6,Comprehensive feedback on sign components, including power supply, surge, and actual air flow/
| Item | YHT-VMS-OT12 | YHT-VMS-OT16 |
| Pixel pitch | 12mm | 16mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 6944 pixels/m² | 3906 pixels/m² |
| Module dimension | 192×192 mm | 256×128 mm |
| Cabinet material | 2mm aluminum Alloy | |
| Screen weight | 65kg/m² | |
| Cabinet dimension | 960×960 mm | 1024×1024 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | |
| Brightness adjustment | 32/256 | |
| Color coordinates | C2: EN12966 | C2: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | |
| Display capacity | Text, image, graphics animations | |
| Lifespan | >100000 hrs | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC | |
| Max. Power consumption | 380W/m² | 250W/m² |
| Avg. Power consumption | 120W/m² | 80W/m² |
| Operation temperature | -25~ +60°C | |
| Storage temperature | -40~ +80°C | |
| Store humidity | 15%~ 95% | 15%~ 95% |
| Protection level | IP56(P3:12966) | IP56(P3:12966) |
| Maintenance method | Rear service | Rear service |
