31.25mm Variable Message Signs Traffic Outdoor Highway VMS Board
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-OT31.25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 22 Square Meter/Square Meters |
|---|---|
| Price: | $1200-2500 Square Meter/Square Meters |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 16 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3980 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixels: | 31.25mm | Display Function: | Graphics, Video, Text |
|---|---|---|---|
| Display Control: | Asynchronous Control System Available | Refresh Rate: | >90+ Hz |
| Pixel Density: | 1024 Pixels/m² | Lifespan: | >100000 Hrs |
| High Light: | 31.25mm Variable Message Signs Traffic,EN12966 Variable Message Signs,31.25mm Highway Digital Signs |
||
Product Description
31.25mm Variable Message Signs Traffic Outdoor Highway VMS Board
P31.25 Highway LED Board VMS Outdoor Traffic Variable Message Signs
Designed and manufactured by YAHAM, the cost effective and P10/P16/P20/P25 Road Side Led Digital Billboard Truck Mounted Folding Traffic Message Car LED VMS Display can play any range of text message,graphics and animations in high visibility color. You can design your own symbols, corporate logos and more.The road side traffic message signs are popular for using in traffic management and advertisement.
1. LED induction screen is designed with double-layer box board, which has good heat dissipation and high reliability.
2. The use of full plastic modular structure, high protection grade, more durable, more reliable products;
3. Adopt parallel current equalization, energy-saving and efficient power supply, support N+1 power backup, further improve reliability;
4. Non-traditional signal transmission technology is adopted to reduce failure rate and improve communication reliability.
5. Each display module of LED induction screen is equipped with intelligent processing chip, which can operate independently and feedback fault independently, making it safe and reliable to use;
6. LED induction screen adopts Linux operating system controller based on ARM, no crash risk, ensure communication security;
7. Intelligent control system, support real-time fault monitoring, monitoring center can master the operation of information board at any time, to ensure road traffic safety;
8. Support four primary colors randomly matched display, highlighting, high transparency.
Minimized power consumption
When a screen is displaying message, for most cases, a large proportion of screen maintain black, Our product is able to detect it and turn this area into sleeping mode .
Second optical lens
It is well know that vms upper viewing angle makes light pollution 505 loss, By applying second lens, we can manufacture 0 ipper viewing angle 0 light pollutions and 0 energy loss
| Item | YHT-VMS-OT25 | YHT-VMS-OT31.25 |
| Pixel pitch | 25mm | 31.25mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 1600 pixels/m² | 1024 pixels/m² |
| Module dimension | 200×200 mm | 250×250 mm |
| Module resolution | 8×8 | 8×8 |
| Cabinet material | 2mm aluminum Alloy | |
| Screen weight | 65kg/m² | |
| Cabinet dimension | 1000×1000 mm | 1000×1000 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | |
| Brightness adjustment | 32/256 | |
| Color coordinates | C2: EN12966 | C2: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz |
| Display capacity | Text, image, graphics animations | |
| Lifespan | >100000 hrs | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC | |
| Max. Power consumption | 220W/m² | 220W/m² |
| Avg. Power consumption | 70W/m² | 70W/m² |
| Operation temperature | -25~ +60°C | |
| Storage temperature | -40~ +80°C | |
| Store humidity | 15%~ 95% | 15%~ 95% |
| Maintenance method | Rear service | Rear service |
| EN12966 | compliance | compliance |
