P20 Variable Message Sign EN12966 Traffic Message Signs 320X160mm For Highway Roads
Product Details:
| Place of Origin: | shenzhen，china |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-OT20-1R1G1B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 11 Square Meter/Square Meters |
|---|---|
| Price: | $1250-2100 Square Meter/Square Meters |
| Packaging Details: | POLY WOODEN CASE |
| Delivery Time: | 27 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3300 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixel Pitch: | 20mm | Screen Weight: | 65kg/m² |
|---|---|---|---|
| Logo: | Customized Logo | Lifespan: | >100000 Hrs |
| Module Dimension: | 8×8 | Brightness: | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) |
| Brightness Adjustment: | 32/256 | Cabinet Dimension: | 960×960 Mm |
| High Light: | aluminum Alloy Variable Message Signs,EN12966 Variable Message Sign,Traffic Message Signs 320X160mm |
||
Product Description
P20 Variable Message Sign En12966 Traffic Message Signs for Highway and Roads 320X160 mm
1) The Freeway VMS signs are designed and manufactured to suit our customers’ specific requirements and we can provide custom engineering solutions for projects of all sizes. We are familiar with the logistics of remote site preparation and the transportation of large electronic equipment in a careful and timely manner for installation and commissioning on site.
2) With low maintenance requirements, superior reliability and power efficiency, our VMS signs are designed for a long service life and ideally suited to harsh environmental conditions.
3) Intuitive user software is provided to program messages locally and remotely. An optional facility key switch for Road Workers, Police or Emergency Services can also be provided for additional security.
High color consistency
With a much improved flatness, diode spectrum and brightness are able to remain the same, making the color more consistent and content more readable
Effortless service
Thanks to the integrated optical len design, no glue coating on the PCB is required, making diode or driver replacement much easier than before.
High stability
Less manual production and component processes, less potential failure rate, bringing the new module up to a new level of stability.
The journeys we make every day are varied. Whether driving through towns and cities or on motorways, we all want mobility which takes us to our destination safely, quickly and conveniently. Flexible and dynamic traffic signalisation is often the best tool to achieve this.
|
Item |
YHT-VMS-OT16 |
YHT-VMS-OT20 |
YHT-VMS-OT25 |
YHT-VMS-OT31.25 |
|
Pixel pitch |
16mm |
20mm |
25mm |
31.25mm |
|
LED type |
3 in1 SMD+lens |
3 in1 SMD+lens |
3 in1 SMD+lens |
3 in1 SMD+lens |
|
Pixel density |
3906 pixels/m² |
2500 pixels/m² |
1600 pixels/m² |
1024 pixels/m² |
|
Module dimension |
256×128 mm |
320×160 mm |
200×200 mm |
250×250 mm |
|
Cabinet material |
2mm aluminum Alloy |
|||
|
Cabinet dimension |
1024×1024 mm |
960×960 mm |
1000×1000 mm |
1000×1000 mm |
|
Brightness |
L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) |
|||
|
Brightness adjustment |
32/256 |
|||
|
Color coordinates |
C2: EN12966 |
C2: EN12966 |
C2: EN12966 |
C2: EN12966 |
|
Viewing angle |
H 15/-15 Deg. / V 8/-10 Deg.(B6:EN12966) |
|||
|
Refresh rate |
>90+ Hz |
>90+ Hz |
>90+ Hz |
>90+ Hz |
|
Display control |
Asynchronous control system available |
|||
|
Display capacity |
Text, image, graphics animations |
|||
|
Lifespan |
>100000 hrs |
>100000 hrs |
>100000 hrs |
>100000 hrs |
|
Power supply |
12-24V DC/110-230V AC |
|||
|
Avg. Power consumption |
80W/m² |
70W/m² |
70W/m² |
70W/m² |
|
Operation temperature |
-25~ +60°C |
|||
|
Storage temperature |
-40~ +80°C |
|||
|
Store humidity |
15%~ 95% |
15%~ 95% |
15%~ 95% |
15%~ 95% |
|
Protection level |
IP56(P3:12966) |
IP56(P3:12966) |
IP56(P3:12966) |
IP56(P3:12966) |
|
Maintenance method |
Rear service |
|||
