P10 LED Traffic Signs Long Lifespan 100000 Hrs Variable Message Signs
Product Details:
| Place of Origin: | shenzhen，china |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-D31.25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 8 Square Meter/Square Meters |
|---|---|
| Price: | $1250-1900 Square Meter/Square Meters |
| Packaging Details: | POLY WOODEN CASE |
| Delivery Time: | 25-35 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3600 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixel Pitch: | 10mm | Pixel Density: | 3944 Pixels/m² |
|---|---|---|---|
| Module Dimension: | 192×192 Mm | Module Resolution: | 16×16 |
| Operating Humidity: | 10%~ 90% | Signal Transfer: | Cat 5 Network Cable, RS232,RS485 Optional |
| Avg. Power Consumption: | 70W/m² | Screen Weight: | 65kg/m² |
| High Light: | P10 LED Traffic Signs,Slimline LED Traffic Signs,100000 hrs Variable Message Signs |
||
Product Description
P10 LED Traffic Signs Improve Safety Lifespan >100000 hrs Variable Message Signs
Slimline Lift Face Signs
Offers flexibility for communicating critical advisories to motorists traveling at low to medium speeds.
Ideal for event management, incident management, and travel time applications.
Designed for roadside or mast-arm mounting.
Lane Management Systems
Communicate lane specific messages to motorists.
Easily and safely reverse lane direction as needed for optimum traffic flow.
1,It is the system that informs the drivers by converting the segment information shown in color on the traffic density map into text or image.
2,It allows drivers to plan their journey using this information. In this way, it helps to use the road network capacity more effectively, reduce traffic density and save time and fuel during the journey.
3,Additionally, it ensures the warning of the drivers about the changing road and weather conditions (accident, icing, fog, etc.) and contributes to the traffic and navigation safety.
The journeys we make every day are varied. Whether driving through towns and cities or on motorways, we all want mobility which takes us to our destination safely, quickly and conveniently. Flexible and dynamic traffic signalisation is often the best tool to achieve this.
| Item | YHT-VMS-D10 | YHT-VMS-D12 |
| Pixel pitch | 10mm | 12mm |
| LED type | 346 DIP | 346 DIP |
| Pixel density | 10000 pixels/m² | 3944 pixels/m² |
| Module dimension | 160×160 mm | 192×192 mm |
| Module resolution | 16×16 | 16×16 |
| Cabinet material | 2mm aluminum Alloy | |
| Screen weight | 65kg/m² | 65kg/m² |
| Cabinet dimension | 960×960 mm | 960×960 mm |
| Brightness | L3: EN12966 (Red: >3100nits, Green>3720nits,Blue>1240nits, Amber>7440nits, | |
| Driving method | 4S | 2S |
| Brightness adjustment | 32/256 | 32/256 |
| Viewing angle | H.110°, V.50° | H.110°, V.50° |
| Refresh rate | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | |
| Signal transfer | Cat 5 Network Cable, RS232,RS485 optional | |
| Display capacity | Text, image, graphics animations | |
| Lifespan | >100000 hrs | >100000 hrs |
| Power supply | 12-24v /220v | 12-24v /220v |
| Max. Power consumption | 300W/m² | 300W/m² |
| Avg. Power consumption | 100W/m² | 100W/m² |
| Operation temperature | -25~ 60°C | |
| Storage temperature | -40~ 80°C | -40~ 80°C |
| Operating humidity | 10%~ 90% | 10%~ 90% |
| Store humidity | 15%~ 95% | 15%~ 95% |
