Waterproof IP65 LED Traffic Display Road Variable Message Board

Product Description

Waterproof IP65 LED Traffic Display Road Variable Message Board

Waterproof grade IP65 road variable message traffic led display sign lifespan >100000 hrs

YAHAM variable message signs and traffic guidance equipment traffic information dissemination, which is based on LED lighting device shows the effect of the basic traffic information display unit of a display device with graphics and text. According to the instruction information traffic, weather and dispatching department, the operator can be released to the variable information boards of various notices and information to effectively induct traffic flow, improve transport capacity of the road network, the safety of the driver driving fast provide excellent service.

PRODUCT FEATURE

1. display module having the versatility and interchangeability can be composed of different display colors and different sizes according to needs.
2. double-box structure, the formation of internal natural convection mode, so cabinets space temperature reaches equilibrium.
3. pixel module junction box and use the "O" ring, with good moisture anti-leakage performance.
4. module package uses advanced soft silicone, the elastic, strong anti-aging ability.
5. power supply, it is important IC device through the heat sink cooling, not only solve the heat, but also to ensure the performance is unstable due to mechanical failure when the cooling fan caused.
6. use special wide temperature range of the device, ensure the normal operation of the display at high or low temperatures.
7.The control system only with the IPC, and higher reliability.
8. use of sophisticated large-scale integrated chip high-speed serial transmission network alternative to discrete parallel transmission chip, reducing the complexity of the transmission display, reducing the complexity of the control system to improve the stability of the product.
9. using the network cable to transmit data to reduce the screen body inside the transmission cable, greatly improve the stability of the display.
10. using a common network data transmission technology, improve gradation display variable message signs, information boards enable a better display.


Variable message signs
Generally speaking, variable message sign is used to communicate in realtime with motorists. variable message sign must address current conditions on the roadway by being dynamic, accurate, timely and understandable.
When there are multiple requests to post VMS messages simultaneously, messages will be prioritized in the following order .YAHAM traffic variable message led display is widely used in highway, city road, highway tunnel road, displaying the road situations info, Traffic command department dispatches information, weather information and so on.

of importance:
1. Incident Management/Public Safety.
2. Congestion Management/Motorist Guidance.
3. Construction/Maintenance Activity.
4. Special Events.
5. Environmental.
6. Law Enforcement Message.


Strong cabinet architecture

2mm Aluminum housing, fully welded with internal strength, ensuring perfect screen performance in the harshest environments and severe weather conditions.

Self –error detection
Every single LED is monitored by master card.Control center will receive warning from master card if there is LED off. User are able to monitor display error remotely.

Auto dimming

Probes are applied to the front and back of the display, it can ensure that the display brightness will change accordingly whether sun exposure to the back of the screen or positive.

High Quality Production
YAHAM use all its raw metarials from ISO certificated products. YAHAM quality staff check all raw metarials before&after all processes to meet quality requirements.

Competitive Price
YAHAM believes to give competitive prices, it should push its own suppliers for competitive prices. YAHAM audit, bargain with its suppliers on behalf of you to reflect decreased prices.

Product Description
low power led display screen, above 50% energy-saving than traditional, but still keep high brightness up to 7500nits,and competitive price

1. Lower power consumption,only need 3.8V and 7.65W for single module,the average power consumption is only 100W/sq.m and 350W/sq.m for max power consumption for screen,that is to say, a panel of 960x960mm only need two power supply

2. DIP led encapsulation confirm high brightness and good heat dissipation,meet to any weather

3. Good waterproof IP65 anti-corrosion,antifogging,long life span>100000Hours

4. Made with high quality Epistar leds keep high quality, low lighting decay, energy saving

5. Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed automatically
