P10 P12 P16 VMS Trailer Signs Full Color LED Display Screen
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | YAHAM |
| Certification: | 2AZPZ-T25 |
| Model Number: | YHT-VMS-OT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD1500-2000/set |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 30days |
| Payment Terms: | Western Union, T/T, L/C, D/P, D/A, MoneyGram |
| Supply Ability: | 1000set/per month |
|
Detail Information |
|||
| Cabinet Material: | 2mm Aluminum Alloy | Screen Weight: | 65kg/㎡ |
|---|---|---|---|
| Display Capacity: | Text,image,graphics Animations | Lifespan: | >100000 Hrs |
| High Light: | P12 VMS Trailer Signs,P12 Truck Mounted Led Screen,P16 Truck Mounted LED Display |
||
Product Description
P10 P12 P16 VMS Trailer Signs Full Color LED Display Screen
Full Color P10 P12 P16 Led Screen Trailer Mobile Led Display Trailer
Product Description
YAHAM mobile LED panel trailer, LED large screen can be folded into the trailer body inside, can protect the LED screen, improve its service life; The technology room can also be set up inside the towed carriage body, which not only brings shocking and changeable visual experience to the audience in appearance, but also adds more functions.
|
ITEM |
OT16 |
OT20 |
OT25 |
OT31.25 |
|
PIXEL |
16mm |
20 mm |
25 mm |
31.25mm |
|
LED TYPE |
3 in 1SMD+LENS |
3 in 1SMD+LENS |
3 in 1SMD+LENS |
3 in 1SMD+LENS |
|
PIXEL DENSITY |
3906 pixel/m2 |
2500 pixel/m2 |
1600 pixel/m2 |
1024 pixel/m2 |
|
MODULE DIMENSION |
256X128 mm |
320X160 mm |
200 x 200 mm |
250 x 250 mm |
|
MODULE RESOLUTION |
16*8 pixels |
16*8 pixels |
8*8 pixels |
8*8 pixels |
|
CABINET DIMENSION |
1024*1024mm |
960*960mm |
1000*1000mm |
1000*1000mm |
|
CABINET WEIGHT |
65kg |
65kg |
65kg |
65kg |
|
ACCESS |
FRONT /BACK |
FRONT /BACK |
FRONT /BACK |
FRONT /BACK |
|
INGRESS PROTECTION |
IP65 |
IP65 |
IP65 |
IP65 |
|
BRIGHTNESS |
12400 NITS |
12400 NITS |
12400 NITS |
12400 NITS |
|
VIEWING ANGLE |
H15/-15 V8/-10 |
H15/-15 V8/-10 |
H15/-15 V8/-10 |
H15/-15 V8/-10 |
|
MAX.POWER CONSUMPTION |
250W |
220W |
220W |
220W |
|
AVE.POWER CONSUMPTION |
80W |
70W |
70W |
70W |
|
DRIVIG METHOD |
STATIC |
STATIC |
STATIC |
STATIC |
|
DISPLAY CONTROL |
Asynchronous control |
Asynchronous control |
Asynchronous control |
Asynchronous control |
|
LED LIFESPAN |
100,000 |
100,000 |
100,000 |
100,000 |
-
New Integrated Optical Len
-
Improved flatness
-
High color consistency
-
Better contrast ratio
-
Effortless replace
-
Thinner cabinet
-
High stability
-
Global positioning system
-
Self-diagnosis and failure report
-
High protection
-
Customized color and sizes
Wireless and remote control
